LATCH Anchor
LATCH Anchor
Near Side
3. Attach Quick Connectors.
Push a Quick Connector onto each seat anchor.
Note: You may need to vary the angle of the Quick
C
onnectors, as shown above, to attach to the anchor.
Also, make sure t
he Quick C
onnector LATCH assembly is
in the forward-facing belt path (p. 40).
IMPORTANT: Make sure both Quick Connectors are facing
upward and the straps are not twisted.
Forward-facing Installation with Quick
Connnectors
Far side
Correct Incorrect
43
Forward-facing
