1. Secure child restraint to the vehicle seat.
• Recline Stand is flipped to the Recline position
(page 18).
• Install with Lower Anchor Connector Assembly
(page 19) or the vehicle seat belt (page 23).
• Towel rolled up and placed beneath the base, if
necessary (page 18).
• Install locking clip, if necessary (page 24).
2. Set the child in the child restraint.
Top of head is at least 25 mm (1 inch) below the
top of the child restraint seat back.
3. Make necessary adjustments.
• Harness straps are snug against the child’s
shoulders, with no slack (page 14).
• Crotch strap is snug against the child (page 39).
4. Fasten the buckle. Refer to page 14.
5. Position and connect chest clip.
Chest clip MUST be at armpit level (page 14).
6. Check your work.
• Recline Stand is flipped to the Recline position
(page 18).
• To properly secure this child restraint it MUST
NOT move more than 25 mm (1 inch) from side
to side or front to back at the rear-facing belt
path (pages 22 and 25).
• The child’s back and bottom are flat against the
back and bottom surfaces of the child restraint.
• Shoulder harness straps MUST start at or below
shoulder height, using the strap slots closest to
your child’s shoulders (page 37).
• Buckle tongues are fully engaged.
• The level arrow is level with ground (page 18).
Using the Tribute™
Rear-facing
25 mm (1 inch)
or more
Rear-facing Installation Checklist
Rear-facing
Child Requirements for Rear-facing:
• Weight: 2.3 to 18 kg (5 to 40 lbs)
• Height: 48 to 94 cm (19 to 37 in.).
AND the t
op of
the child’s head is least 25 mm (1 in.) below the top of
the child restraint seat back.
Note: When in rear-facing position, bottom of child
restraint MUST be entirely on vehicle seat.
