Evenflo Tribute - Forward-Facing with Lower Anchor Assembly

30 31
Forward-facing
Make sure
that the harness
straps are in one of the top three
strap slots
A
.
The harness straps MUST be at
or above shoulder height
B
,
using the strap slots closest to
your child’s shoulders. This will
provide more room for your
toddler to fit comfortably.
WARNING
DO NOT use the lowest set of harness slots for
forward-facing. The harness may not properly restrain
the child in the event of a crash.
2
A
B
1
Place the child restraint in your vehicle forward-
facing. Route the lower anchor connector strap and
hook through the forward-facing belt path
C
.
C
E
D
E
D
Refer to your vehicle owner’s manual to locate the
lower anchor bars on your vehicle seat. Attach the
right hook
D
to the right anchor bar
E
, and the left
hook to the left anchor bar.
DOUBLE CHECK that the lower anchor connector
hook is fully engaged by pulling hard on the lower
anchor connector strap.
DO NOT use this child restraint if it moves more than
25 mm (1 in.) side-to-side or front to back at the
forward-facing belt path. Serious injury or death may result
from poor installation. If you can not tightly secure the child
restraint, try again, move it to another location, or install
with the vehicle seat belt.
3
WARNING
4
C
Using your full weight, push the child restraint firmly
into the vehicle seat, while pulling up on the lower
anchor connector strap to tighten.
The lower anchor connector strap must be as tight
as possible. If you can move the child restraint more
than 25 mm (1 in.) side to side or front to back at
the belt path
C
, the lower anchor connector strap is
not tight enough. You will need to try again, find
another location for your child restraint, or install with
the vehicle seat belt (page 33). To remove the lower
anchor connector strap, go to page 41.
