General
Information
There are two positions on the harness straps.
The top loop
E
is for infant use. The bottom loop
F
is for use as your child grows.
Reattach the harness
strap onto the splitter plate
D
. Repeat on the other side.
1
Pull harness strap
through to the front
of the child restraint.
Thread each harness
strap through the
appropriate slot in
the seat shell and
the pad.
Pull the harness strap
to the back of the
child restraint.
To change the harness strap position, loosen the
shoulder harness, as shown on page 39, step 2.
Slide the harness strap off of the splitter plate
D
.
We suggest you do this one side at a time.
D
1
2
Ä
Adjusting the Harness Strap
1
To tighten the harness
straps, pull on the long
harness adjuster strap
A
on the front of the seat.
To loosen the harness
straps, push the harness
release button
B
on the
front of the seat. At the
same time, pull up on the
harness strap
C
near the
child’s shoulders.
2
A
B
C
Adjusting the Crotch Strap
To reposition the crotch strap, first turn the child
restraint upside down. Turn the crotch strap harness
anchor
A
sideways and push it through the slot in
the bottom of the seat shell
B
.
Reposition the harness anchor into the other slot.
Make certain the harness anchor is properly seated
against the seat shell
B
.
Note: The crotch strap should be snug against the
child; choose the slot that is closest to the child AND
the most comfortable for the child.
This Child Restraint Has Two Buckle Harness Positions
A
B
A
IMPORTANT: Make sure both harness straps are
installed completely on the splitter plate, as shown.
3
D
F
Toddler
D
E
Infant
Toddler
Infant
