Evenflo Tribute - Installing the Child Restraint Rear-facing with a Seat Belt

22 23
5
DO NOT use this child restraint if it moves more than
25 mm (1 in.) side-to-side or front to back at the rear-
facing belt path. Serious injury or death may result from
poor installation. If you can not tightly secure the child
restraint, try again or move it to another location, or
install with the vehicle seat belt.
WARNING
D
Using your full weight, push the child restraint firmly
into the vehicle seat while pulling up on the lower
anchor connector assembly strap to tighten.
The lower anchor connector assembly strap must be
as tight as possible.
If you can move the child restraint more than 25 mm
(1 inch) side to side or front to back at the rear-facing
belt path
D
, the lower anchor connector assembly strap
is not tight enough. You will need to try again, find
another location for your child restraint, or install with
the vehicle seat belt (page 23).
To remove the lower anchor connector assembly strap ,
go to page 41.
Make sure that the harness
straps are in one of the three
lower harness positions
A
.
The harness straps must start
at or below shoulder height,
using the strap slots closest
to your child’s shoulders
B
,
as shown.
Infants MUST always ride
facing the rear of the
vehicle. The back of the
child restraint supports
and protects the baby and
absorbs crash forces.
NEVER turn a child restraint
forward-facing with an infant
weighing less than 10 kg (22 lbs)
or less than one year of age.
Crash forces may cause serious
injury or death.
A
WARNING
Installing the Child Restraint
Rear-facing with a Seat Belt
B
DO NOT use the upper harness slots rear-facing. The harness
may not properly restrain the child during a crash.
WARNING
Adjust the child restraint to the Recline position (p. 18).
Place the child restraint in your vehicle rear-facing.
1
Rear-facing
