Min. Illumination
Color: 0.2 Lux at F1.4
B/W: 0.05 Lux at F1.4
Electronic Shutter 8.5 ~ 1/60,000sec.
Scanning System NTSC / PAL
WDR Yes
BLC Yes
Gain Control Yes
White Balance Yes
Lens
Lens Type Fixed Lens
Focal Lens 3.6 mm / 6 mm
Aperture Ratio F1.4
Day / Night True Day / Night with IR cut filter
Video
Video Compression H.264 / MJPEG / MPEG4 (optional)
Resolution
NTSC
1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768, 720 x 480, 704 x
480, 640 x 480, 352 x 240, 320 x 240, 160 x 120
PAL
1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768, 720 x 576, 704 x
576, 640 x 480, 352 x 288, 320 x 288, 160 x 120
Frame Rate 30 fps at 1920 x 1080
Network
Interface
10BASE-T / 100BASE-TX auto-negotiation, RJ-45 socket
Support MDI / MDI-X auto crossover function
Supported Protocols
TCP / IP, IPV6, UDP, ICMP, DHCP, NTP, DNS, DDNS, SMTP, SNMP, FTP,
HTTP, HTTPs, PPPoE, UPnP, Bonjour, RTP, RTSP, RTCP, UDP, IGMP,SSL,
ICMP, ARP, ONVIF, PSIA, QoS
Bandwidth control Min. 256 k Byte / sec adjustable
