FAN: Cooling FAN.
11
12
13
Remote Control: Remote control port provides you an extension wire with an IR receiver instead of
the IR receiver on the front panel.
Note: The IR receiver extension line (10m) must be purchased separately.
Antenna: Integrated IEEE 802.11b/g wireless LAN capabilities. The antenna port is for wireless
network antenna use (For EDR810M option).
Remote
Wireless LAN
10
USB slot: USB port allows you to archive files into your storages.
USB
(Reserved)
16
LAN Connector: The RJ-45 LAN connector.
LAN
7
RS232
RS232 connector: Connect D-Sub 9 pins connector to RS232 ports for remote control.
8
RS485
RS485 connector: RJ 45 Connector to Cascade multi Digital Video Recorder.
9
