The installations described below should be done by qualified service personnel or system installers.
2.1 PACKING LIST
2. INSTALLATION
Please check accessories in the packing before the installation.
Camera
(VIDEO & AUDIO)
Monitor
(and Speaker)
Internet
Alarm
(In & Out)
IR Remote Controller
(Extension Line Connector)
USB Device
(Storage)
RS 232
Please refer to the following diagram for the system connections.
Note: Monitor and Camera must be purchased separately.
2.2 SYSTEM FLOORPLAN
Call
Monitor
Antenna (Mobile Model only)
Keyboard
Note: 810H/810M without relay
410H/410M with relay
