EPA6220 / EPA6236
5
2.3 Pole Mounting
You can purchase the Pole Mount Bracket (please refer to 1.4 Optional Accessories) to install the speed
dome camera to a pole structure with diameter between 130-152mm (max. 6 inches). Note that the pole
structure should be withstood at least 4 times the weight of the speed dome camera.
Pole Mount Bracket
1. Fix the Pole Mount Bracket to the pole structure using the Stainless Hose Clamps (φ130-152mm).
2. Run the cables through the Wall Mount Bracket and Pole Mount Bracket, and then screw the Wall
Mount Bracket to the Pole Mount Bracket.
3. Screw the speed dome camera to the Wall Mount Bracket.
