EverFocus EPA6220 - 4 OSD Menu; System

EPA6220 / EPA6236
10
4. OSD Menu
MAIN MENU
<
SYSTEM >
< DOME >
< CAMERA >
< DISPLAY >
< LANGUAGE >
< TIMING TASK >
< ALARM >
< RESET >
EXIT
4.1 System
MAIN MENU
< SYSTEM >
< DOME >
< CAMERA >
< DISPLAY >
< LANGUAGE >
< TIMING TASK >
< ALARM >
< RESET >
EXIT
SYSTEM
MFG
PROTOCOL
DOME ID
COMM
TEMPERATURE
VERSION
EXIT
AUTO
001
9600-N-8-1
33
A123456
MFG: Max 15 characters displayed on the screen.
PROTOCOL: Displays the protocol of the dome. To configure the value, go to DOME > COMM.
DOME ID: Displays the dome address. To configure the value, go to DOME > COMM.
COMM: Displays the baud rate, check bit, data bit, start bit. To configure the value, go to DOME > COMM.
TEMPERATURE: Displays the temperature of the dome.
VERSION: Displays the version of the dome.
EXIT: Exit the current menu.
