CP-2272E
Revision 1.0 Page 5
3. TECHNICAL DESCRIPTION
3.1. SPECIFICATIONS
3.1.1. Control
• Joystick Parallel contact closure TTL levels, D9 male
• Ethernet 10/100 base T, RJ45 connector
3.1.2. Electrical
Voltage: +12V
Power: 24 Watts maximum
Fuse Rating: 2A
3.1.3. Physical
Height: 3.47” (88.14mm)
Width: 19.04” (483.62mm)
Depth: 3.911” (99.34mm)
Weight: 3lbs (1.36kg)
Operating Temp: 0-40°C
3.1.4. Compliance
Safety: ETL Listed, complies with EU safety directives
EMI/RFI: Complies with FCC Part 15 Class A regulations
Complies with EU EMC directive
