Once the IP address is set, use the Save and Exit button to save the changes and return to the top
level Setup menu.
4.2.1.2. Setting the Netmask
The Netmask menu item is used to set the netmask address of the CP-2272E control panel.
The netmask is displayed in the following format:
aaa.bbb.ccc.ddd
To change a value, psuh the button containing the value you want to change and use top level rotary
encoder to change the Netmask values. To change the value, rotate the encoder clockwise or counter-
clockwise. To move to the next three digits of the address, push the next button containing the value
you want to change.
Once the Netmask is set, use the Save and Exit button to save the changes and return to the top level
Setup menu
4.2.2. Setting the Broadcast Address
The Broadcast menu item is used to set the broadcast address for the CP-2272E control panel.
The broadcast address is displayed in the following format:
aaa.bbb.ccc.ddd
To change a value, push the button containing the value you want to change and use top level rotary
encoder to change the Broadcast Address values. To change the value, rotate the encoder clockwise
or counter-clockwise. To move to the next three digits of the address, push the next button containing
the value you want to change.
Once the Broadcast address is set, use the Save and Exit button to save the changes and return to
the top level Setup menu.
4.2.3. Setting the Gateway
The Gateway menu item is used to set the gateway address for the CP-2272E control panel.
The gateway address is displayed in the following format:
aaa.bbb.ccc.ddd
To change a value, push the button containing the value you want to change and use top level rotary
encoder to change the Gateway Address values. To change the value, rotate the encoder clockwise or
counter-clockwise. To move to the next three digits of the address, push the next button containing the
value you want to change.
Once the Gateway address is set, use the Save and Exit button to save the changes and return to the
top level Setup menu.
