Telescopic boom Machine ER2500- THE OPERATOR’S
MANUAL
DANGER
Each attachment refers to its norms of product. The tipping moment generated by the
equipment installed on the machine must be lower than the one produced by the
loads stated in the chart. The weight of the equipment installed on the machine must
be considered as an applied tool.
2.4.2 NOISE RISK
ATTENTION
The machine may produces high noisiness when operated, so the use of soundproof
protection tools to avoid damages to the auditory system is obligatory.
2.4.3 LOAD DIAGRAMS
The tipping load is limited to the possibility of inclination of the machine. The load
diagrams represented illustrates the inclination of load and the maximum weight of
lifting in different positions of the arm and with different distance from the machine.
The load diagrams refer to the machine in still position and set on a solid and plain
surface with an operator of 85kg in the driving seat.Any shift in the center of gravity of
the load produces a change in the machine’s loading capacity.
The stated lifting capacity is inclusive of the weight of the accessory used, the net
lifting is therefore given by the value shown on the graph less the weight of
accessory.
