Multifunction Machine ER2500- THE OPERATOR’S MANUAL
3.1.9 Hydraulic output control lever.
Push it forwards, the quick hitch cylinder is engaged with the attachment, push it
backwards, removes the attachment.
ATTENTION
When finish the action of the joystick or levers, make sure that they are at neutral
position.
3.1.10 IGNITION KEY
Rotating the key to the right turns on the power supply, a second click to the right
turns on the engine. Once the machine is on, release the key. To turn the machine off,
turn the key to the left.
3.1.11 Handbrake
When the machine was stopped, engage the parking brake to make sure that the
machine doesn’t move. Before driving the machine, release this brake.
3.1.12 The Plug Pin of Quick Change connector
The plug pin is controlled by the block valve operated by hand.
Picture 3.1.3
