Section 3
Hardee by EVH
Assembly and Installation
LR50160 Long Reach Mower 7
Component Identification and Terminology
A Weight Box M Deck
B Flow Ezy Breather N Motor Drive Housing
C Oil Tank O Rubber Shielding
D Return Filter P 2
nd
Stage (Reach) Boom
E Swing Cylinder Q 2
nd
Stage Cylinder
F Hitch Frame R Lift Break-Away
G Swing Post S 1
st
Stage Cylinder
H Hose Guard T Short Stand
I 1
st
Stage (Lift) Boom U Long Stand
J Deck Cylinder V Hydraulic Pump
K Deck Linkage W Oil Cooler
L Hydraulic Motor
