DWG.
NO.
25695
B
DWG SIZE
DO NOT
SCALE
LR50160 COMPLETE
SHEET 1 of 10
DESCRIPTION
HARDEE BY
EVH MFG. CO.
LORIS S.C.
R.M.N.
N/A
Manufactured By:
EVH Mfg. Co., LLC
MATERIAL
MODELED
BY
T.B.B. 3/11/14
DRAWN
BY
C.K.N. 3/23/10
Decimal Dim. to Limits Shown All Holes to be +0 -1/32"
Tolerance Unless Otherwise Specified
All Dimensions in Inches Unless Otherwise Specified
Dimensions in [ ] are in Millimeters
Item
Part
Number
Qty. Description
1 10002 2 Hex Bolt, 1/4"-20 X 1" Gr.5 Plated
2 10006 6 Hex Bolt 1/4" x 3" gr.5 plated
3 10031 13 Hex Bolt 3/8 x 1 gr.5 plated
4 10032 1 Hex Bolt 3/8 x 1-1/2 gr.5 plated
5 10034 2 Hex Bolt 3/8" x 2-1/2" gr.5 plated
6 10041 2 HEX BOLT (3/8" X 6" GR. 5 PLATED)
7 10071 10 Hex Bolt 1/2 x 1 gr.5 plated
8 10072 2 Hex Bolt 1/2 x 1 1/2 gr.5 plated
9 10092 4 Hex Bolt 5/8 x 2 gr.5 plated
10 10093 2 Hex Bolt 5/8" x 2-1/2" gr.5 plated
11 10111 4 Hex Bolt 3/4"-10 X 2" gr.5 Plated
12 10135 2 HEX BOLT(M6x1x20MM GR.5 ZINC)
13 10153 6 Lock Nut, 1/4" Plated
14 10154 1 Lock Nut 5/16"-18 Plated
15 10166 12 Lock Nut 5/8"-11 plated
16 10168 14 3/4"-10 Locknut (Gr.5 Plated)
17 10175 13 3/8"-16 Locknut (Gr.5 Plated)
18 10176 8 1/2" Locknut (Gr.5 Plated)
19 10181 1 Lockwasher 5/16" plated
20 10184 8 Lockwasher 1/2 plated
21 10185 2 Lockwasher 5/8" Plated
22 10186 10 Lockwasher 3/4" Plated
23 10200 6 1/4" Plated Flatwasher
24 10202 25 3/8" Flatwasher (Plated)
25 10204 20 1/2 Flatwasher (Plated)
26 10206 8 Flatwasher 3/4 plated
27 10207 23 Flatwasher, 1" plated
28 10252 12 Cotter Pin 3/16" X 2" Plated
29 10335 1 Hardee Red Paint - (Not Shown)
30 10336 1 Gear Oil [85W-140] - (Not Shown)
31 10339 2 Pop Rivet
32 10346 2 3 pt. Snap Pin (Lynch Pin)
33 10368 1 1-1/4" Gate Valve
34 10373 1 Hydraulic Oil
35 10387 2 O-ring
36 10388 1 O-Ring
37 10390 3 Clip Pin (1/8 x 2)
38 10393 3 Universal Clip Pin
39 10419 2 Hitch Pin, Cat. 2 & 3, Clevis Style
40 10501 1 FLOW EZY BREATHER
41 10538 2 Sleeve for 10419 Pin
42 10582 1 PRESSURE HOSE 3/8" X 55" W/6-F-JIC
43 10583 1 3/8" SAE 100 R1 X 125" W/6-F-JIC
44 10584 1 PRESSURE HOSE 3/8" X 210" W/6-F-JIC
45 10585 2 PRESSURE HOSE 3/8" X 83" W/6-F-JIC
46 10587 1 PRESSURE HOSE 3/4" X 106" W/12-M-JIC
47 10646 1 Grease
48 10866 1 1" X 106" Pressure Hose
49 10872 4 Pressure Flange SET
50 11005 1 Decal, Warning - Thrown Objects
51 11010 3 Large Hardee Logo Decal
52 11032 1 Small Hardee Logo Decal
53 11675 1 Return Filter Assembly
54 11727 1 Serial Number Plate
55 11850 1 Web Site Decal
56 11860 10 TIE STRAP, (14" LG.) (100/PK)
57 13535 4 STAINLESS STEEL CLAMP, 1-1/2" TO 1-3/4"
58 13563 1 1-1/4"-M-NPT X 1-1/2" Metal Hose Barb
59 13632 1 1/4" NPT Metal Cap
60 13697 1 1-1/4" NPT Female Threaded Elbow
61 13758 1 20-M-NPT X 16-F-NPT Reducer
62 13778 1 1-1/4" X 3-1/2" Long NPT Nipple
63 13902 8 STRAIGHT, 6-M-JIC X 8-M-ORB
64 13905 8 6-M-JIC X 8-M-NPT 90 Deg. Elbow
65 13974 1 16-M-JIC X 16-M-NPT 90 Deg. Elbow
66 15242 1 Hydraulic Vane Motor
67 15251 2 1" Hose Clamp Body (SET OF 2)
68 15252 1 3/4" Hose Clamp Body (SET OF 2)
69 15255 3 Hose Clamp Cover Plate
70 15256 2 Hex Bolt (1/4" X 2-3/8" Gr. 5 Plated)
71 15326 1 Pressure Hose 3/8" X 17" Lg. W/ 6-F-JIC Both Ends
72 15338 1 Danger Decal, Exposed Blades
73 15339 1 PRESSURE HOSE 3/8" X 32" W/6-F-JIC
74 15466 2 Tubing Insert, 3-1/2" Sqr. X 11
75 15481 1 Slotted Hex Nut 1-1/4" -18UNEF
76 15845 1 Hydraulic Decal Kit
77 15845-1 1 DANGER DECAL (KIT 15845)
78 15845-10 1 WARNING DECAL (KIT 15845)
79 15845-11 1 WARNING DECAL (KIT 15845)
80 15845-15 1 DANGER DECAL (KIT 15845)
81 15845-16 1 DANGER DECAL (KIT 15845)
82 15845-9 1 WARNING DECAL (KIT 15845)
83 15852 2 Red Reflector Decal
84 15853 2 Yellow Reflector Decal
85 15854 1 Manual Holder
86 15860 2 U-Nut, 1/4"-20
87 15910 46 HOSE SLEEVE
88 15968 1 Cotter Pin 1/4" x 3"
89 16065 1 CONTROL VALVE & Joy Stick Kit
90 16067 1 PUMP - VALVE HOSE
91 16068 1 HOSE ASSY. VALVE TO TANK
92 16070 8 3/8" - 90DEG. SWIVEL NUT
93 16071 1 PRESSURE HOSE 3/8" X 192" W/6-F-JIC
94 16077 3 Straight Fitting - 1"
95 16084 2 Swivel Nut Run Tee - 37 Deg. Flare
96 16086 1 Reducer 37 Deg. Flare (16-12 TRTXN-S)
97 16100 1 Sight Gauge 5", With Thermometer
98 16138 2 Lock Nut 7/16"-14 NC with Nylon Insert
99 16191 2 16-M-JIC X 16-M-NPT 90 Deg. Elbow
100 16249 1 PROX SENSOR
101 16278 1 Joystick Assembly (Not Shown)
102 16335 1 Hour Meter - not for resale
103 16339 3 DECAL, MODEL LR50160
104 16353 2 16 M-JIC - 12 MORB Elbow
105 16354 1 Fitting, 16-M-ORB/16-F-JIC0
106 16379 1 HYDRAULIC HOSE, 1" - OIL
107 16390 1 HYD. HOSE, 1" 5 PSI RELIEF - OIL FILTER
108 16392 1 PRESSURE HOSE 3/4" X 143" LG
109 16393 1 PRESSURE HOSE 1" X 153" LG
110 16404 1 CHECK VALVE- INLINE 5 PSI
111 16431 1 WIRING HARNESS, Oil Cooler
112 16436 1 Clamp, 1/2" Plated Steel Loom
113 16496 1 CONTROLLER, MC 024 020 for 16065
114 16579 1 Hydraulic Motor Housing Assembly
115 16617 1 OIL COOLER
116 16618 1 TEMPERATURE SWITCH
117 16747 2 CYLINDER, 3 X 17"
118 16751 1 CYLINDER, 4 X 24 TIE ROD, Long Rod, LR"
119 16845 1 Cylinder, 4" X 24" With 2.0" Rod
120 20031 1 Access Cover
121 22710 1 Short Belting Flat
122 22728 1 DB4060/LR50160 Rubber Belting Kit
123 22768 1 LR50160 Front Corner Belting
124 22770 1 LR40148 / LR50148 Belting Extension Kit
125 22781 1 LR50160 Deck Weldment (6 Bolt)
126 22833 2 Fluid Connector
127 23130 1 Pivot Sleeve
128 23131 1 End Cap Weldment
129 23160 2 Stand Weldment, 17-7/8" Tall
130 23232 1 Support Brace
131 23280 1 WELDMENT, Cylinder Breakaway
132 23287 2 Boom To Deck Bracket Weldment
133 23290 2 WELDMENT, Boom to Deck Bracket, 21"
134 23292 1 PIN WELDMENT (1" x 5" LG)
135 23294 1 1st Stage Boom
136 23310 1 2nd Stage Boom
137 23320 1 Cylinder Mount Weldment
138 23325 1 WELDMENT, Weight Box
139 23335 1 Weldment, Oil Tank
140 23340 1 Stand Weldment
141 23345 1 Head Mounting Bracket Weldment
142 23349 1 Outer Hose Guard Weldment
143 23352 1 Inner Hose Guard Weldment
144 23355 1 WELDMENT, GUARD
145 23361 2 Spacer, 1" X 2-1/8"
146 23363 2 SPACER (1" SCH 40 Pipe x 5/8")
147 23379 2 1-1/4" X 9" Pin Weldment for LR's
148 23380 1 WELDMENT, 1" x 6 1/4" PIN
149 23434 5 Pin Weldment
150 23457 2 COLLAR, for 23379 PIN (Bushing)
151 25117 2 Spacer
152 25724 5 WELDMENT, Cylinder Pin
153 25725 1 WELDMENT, Hardee Logo
154 25798 1 Hose, Suction (1-1/2" x 36")
155 25841 1 BLADE HOLDER WITH BLADES, LR50160
156 25857 1 WELDMENT-OIL COOLER SUPPORT
157 25930 1 ASSEMBLY Hitch Frame, LR50160 / LR50148
158 26855 1 WELDMENT - FAN GUARD FOR OIL COOLER
REV CHANGE BY DATE ECN
C
Modeled & Re-Drawn in Creo 2.0
T.B.B. 3/11/14 1572
D
Stand Weldment Replaced (23160 was 23038)
T.B.B. 1/19/16 1620
E
Pump 15240 Has Changed To Pump 16705 T.B.B. 12/14/16 1672
Cylinder 10448 Has Changed To Cylinder 16747
T.B.B. 1/16/17 1655
F
Cylinder 15928 Has Changed To 16750
Cylinder 10454 Has Changed To 16751
T.B.B. 2/3/17 1672
G
16845 REPLACED 16750 (Hyd. Cylinder) V.A.M. 8/11/17 1686
G
25695
DWG.
NO.
LR50160 Complete
Note:
This list of components is strictly to be
viewed as a "BILL OF MATERIALS"
of the "COMPLETE" mower. It is not
related to any illustration.
29
