DWG.
NO.
25695
B
DWG SIZE
DO NOT
SCALE
LR50160 COMPLETE
SHEET 9 of 10
DESCRIPTION
HARDEE BY
EVH MFG. CO.
LORIS S.C.
R.M.N.
N/A
Manufactured By:
EVH Mfg. Co., LLC
MATERIAL
MODELED
BY
T.B.B. 3/11/14
DRAWN
BY
C.K.N. 3/23/10
Decimal Dim. to Limits Shown All Holes to be +0 -1/32"
Tolerance Unless Otherwise Specified
All Dimensions in Inches Unless Otherwise Specified
Dimensions in [ ] are in Millimeters
Item
Part
Number
Qty. Description
1 10031 8 Hex Bolt 3/8 x 1 gr.5 plated
2 10071 8 Hex Bolt 1/2 x 1 gr.5 plated
3 10092 4 Hex Bolt 5/8 x 2 gr.5 plated
4 10166 4 Lock Nut 5/8"-11 plated
5 10175 4 3/8"-16 Locknut (Gr.5 Plated)
6 10184 8 Lockwasher 1/2 plated
7 10202 12 3/8" Flatwasher (Plated)
8 10336 1 Gear Oil [85W-140] - (Not Shown)
9 10368 1 1-1/4" Gate Valve
10 10373 1 Hydraulic Oil
11 10387 2 O-ring
12 10501 1 FLOW EZY BREATHER
13 10582 1 PRESSURE HOSE 3/8" X 55" W/6-F-JIC
14 10583 1 3/8" SAE 100 R1 X 125" W/6-F-JIC
15 10584 1 PRESSURE HOSE 3/8" X 210" W/6-F-JIC
16 10585 2 PRESSURE HOSE 3/8" X 83" W/6-F-JIC
17 10587 1 PRESSURE HOSE 3/4" X 106" W/12-M-JIC
18 10646 1 Grease
19 10866 1 1" X 106" Pressure Hose
20 10872 2 Pressure Flange SET
21 11675 1 Return Filter Assembly
22 11775 1 Hydraulic 540RPM Pump
23 13535 4 STAINLESS STEEL CLAMP, 1-1/2" TO 1-3/4"
24 13563 1 1-1/4"-M-NPT X 1-1/2" Metal Hose Barb
25 13697 1 1-1/4" NPT Female Threaded Elbow
26 13758 1 20-M-NPT X 16-F-NPT Reducer
27 13778 1 1-1/4" X 3-1/2" Long NPT Nipple
28 13902 8 STRAIGHT, 6-M-JIC X 8-M-ORB
29 13905 8 6-M-JIC X 8-M-NPT 90 Deg. Elbow
30 13974 1 16-M-JIC X 16-M-NPT 90 Deg. Elbow
31 15242 1 Hydraulic Vane Motor
32 15326 1 Pressure Hose 3/8" X 17" Lg. W/ 6-F-JIC Both Ends
33 15339 1 PRESSURE HOSE 3/8" X 32" W/6-F-JIC
34 15910 46 HOSE SLEEVE
35 16065 1 CONTROL VALVE & Joy Stick Kit
36 16067 1 PUMP - VALVE HOSE
37 16068 1 HOSE ASSY. VALVE TO TANK
38 16070 8 3/8" - 90DEG. SWIVEL NUT
39 16071 1 PRESSURE HOSE 3/8" X 192" W/6-F-JIC
40 16077 3 Straight Fitting - 1"
41 16084 2 Swivel Nut Run Tee - 37 Deg. Flare
42 16086 1 Reducer 37 Deg. Flare (16-12 TRTXN-S)
43 16191 2 16-M-JIC X 16-M-NPT 90 Deg. Elbow
44 16278 1 Joystick Assembly (Not Shown)
45 16353 2 16 M-JIC - 12 MORB Elbow
46 16354 1 Fitting, 16-M-ORB/16-F-JIC0
47 16379 1 HYDRAULIC HOSE, 1" - OIL
48 16390 1 HYD. HOSE, 1" 5 PSI RELIEF - OIL FILTER
49 16392 1 PRESSURE HOSE 3/4" X 143" LG
50 16393 1 PRESSURE HOSE 1" X 153" LG
51 16404 1 CHECK VALVE- INLINE 5 PSI
52 16431 1 WIRING HARNESS, Oil Cooler
53 16617 1 OIL COOLER
54 16618 1 TEMPERATURE SWITCH
55 16705 1 Hydraulic 1000RPM Pump
56 16747 2 CYLINDER, 3 X 17"
57 16751 1 CYLINDER, 4 X 24 TIE ROD, Long Rod, LR"
58 16845 1 Cylinder, 4" X 24" With 2.0" Rod
59 22833 2 Fluid Connector
60 23335 1 Weldment, Oil Tank
61 25798 1 Hose, Suction (1-1/2" x 36")
540 RPM - P/N: 11775
1000 RPM - P/N: 16705
Pump Options
REV CHANGE BY DATE ECN
C
Modeled & Re-Drawn in Creo 2.0
T.B.B. 3/11/14 1572
D
Stand Weldment Replaced (23160 was 23038)
T.B.B. 1/19/16 1620
E
Pump 15240 Has Changed To Pump 16705 T.B.B. 12/14/16 1672
Cylinder 10448 Has Changed To Cylinder 16747
T.B.B. 1/16/17 1655
F
Cylinder 15928 Has Changed To 16750
Cylinder 10454 Has Changed To 16751
T.B.B. 2/3/17 1672
G
16845 REPLACED 16750 (Hyd. Cylinder) V.A.M. 8/11/17 1686
G
25695
DWG.
NO.
Hydraulic Schematic For LR50160
[Pump BOM Quantity Notes]
10071 - 4 Per Motor
10092 - 2 Per Motor
10166 - 2 Per Motor
10184 - 4 Per Motor
10387 - 1 Per Motor
22833 - 1 Per Motor
3
2
6
11
20
59
4
16075
O-Ring
15728
Seal Kit
16538
Shaft & Bearing Assy.
4
3
2
6
11
59
16075
O-Ring
15728
Seal Kit
16706
Shaft & Bearing Assy.
37
To Next Page
