Evh HARDEE LR50160 User Manual

DWG.
NO.
25695
B
DWG SIZE
DO NOT
SCALE
LR50160 COMPLETE
SHEET 3 of 10
DESCRIPTION
HARDEE BY
EVH MFG. CO.
LORIS S.C.
R.M.N.
N/A
Manufactured By:
EVH Mfg. Co., LLC
MATERIAL
MODELED BY
T.B.B. 3/11/14
DRAWN BY
C.K.N. 3/23/10
Decimal Dim. to Limits Shown All Holes to be +0 -1/32"
Tolerance Unless Otherwise Specified
All Dimensions in Inches Unless Otherwise Specified
Dimensions in [ ] are in Millimeters
Item
Part
Number
Qty. Description
1 10002 2 Hex Bolt, 1/4"-20 X 1" Gr.5 Plated 2 10006 2 Hex Bolt 1/4" x 3" gr.5 plated 3 10031 11 Hex Bolt 3/8 x 1 gr.5 plated 4 10032 1 Hex Bolt 3/8 x 1-1/2 gr.5 plated 5 10041 2 HEX BOLT (3/8" X 6" GR. 5 PLATED) 6 10072 2 Hex Bolt 1/2 x 1 1/2 gr.5 plated 7 10092 2 Hex Bolt 5/8 x 2 gr.5 plated 8 10135 2 HEX BOLT(M6x1x20MM GR.5 ZINC) 9 10153 2 Lock Nut, 1/4" Plated
10 10166 2 Lock Nut 5/8"-11 plated 11 10175 7 3/8"-16 Locknut (Gr.5 Plated) 12 10176 6 1/2" Locknut (Gr.5 Plated) 13 10200 6 1/4" Plated Flatwasher 14 10202 19 3/8" Flatwasher (Plated) 15 10204 8 1/2 Flatwasher (Plated) 16 10368 1 1-1/4" Gate Valve 17 10387 1 O-ring 18 10390 3 Clip Pin (1/8 x 2) 19 10393 3 Universal Clip Pin 20 10501 1 FLOW EZY BREATHER 21 10872 1 Pressure Flange SET 22 11005 1 Decal, Warning - Thrown Objects 23 11010 3 Large Hardee Logo Decal 24 11675 1 Return Filter Assembly 25 11850 1 Web Site Decal 26 13535 4 STAINLESS STEEL CLAMP, 1-1/2" TO 1-3/4" 27 13563 1 1-1/4"-M-NPT X 1-1/2" Metal Hose Barb 28 13632 1 1/4" NPT Metal Cap 29 13697 1 1-1/4" NPT Female Threaded Elbow 30 13758 1 20-M-NPT X 16-F-NPT Reducer 31 13778 1 1-1/4" X 3-1/2" Long NPT Nipple 32 13902 8 STRAIGHT, 6-M-JIC X 8-M-ORB 33 13974 1 16-M-JIC X 16-M-NPT 90 Deg. Elbow 34 15466 2 Tubing Insert, 3-1/2" Sqr. X 11 35 15845-15 1 DANGER DECAL (KIT 15845)
36 15845-16 1 DANGER DECAL (KIT 15845) 37 15845-9 1 WARNING DECAL (KIT 15845) 38 15852 1 Red Reflector Decal 39 15853 1 Yellow Reflector Decal 40 15854 1 Manual Holder 41 15860 2 U-Nut, 1/4"-20 42 16065 1 CONTROL VALVE & Joy Stick Kit 43 16070 8 3/8" - 90DEG. SWIVEL NUT 44 16077 3 Straight Fitting - 1" 45 16084 2 Swivel Nut Run Tee - 37 Deg. Flare 46 16086 1 Reducer 37 Deg. Flare (16-12 TRTXN-S) 47 16100 1 Sight Gauge 5", With Thermometer 48 16191 2 16-M-JIC X 16-M-NPT 90 Deg. Elbow 49 16249 1 PROX SENSOR 50 16339 3 DECAL, MODEL LR50160 51 16353 2 16 M-JIC - 12 MORB Elbow 52 16354 1 Fitting, 16-M-ORB/16-F-JIC0 53 16404 1 CHECK VALVE- INLINE 5 PSI 54 16436 1 Clamp, 1/2" Plated Steel Loom 55 16496 1 CONTROLLER, MC 024 020 for 16065 56 16617 1 OIL COOLER 57 16618 1 TEMPERATURE SWITCH 58 22833 1 Fluid Connector 59 23160 2 Stand Weldment, 17-7/8" Tall 60 23232 1 Support Brace 61 23325 1 WELDMENT, Weight Box 62 23335 1 Weldment, Oil Tank 63 23340 1 Stand Weldment 64 25725 1 WELDMENT, Hardee Logo 65 25857 1 WELDMENT-OIL COOLER SUPPORT 66 25930 1 ASSEMBLY Hitch Frame, LR50160 / LR50148 67 26855 1 WELDMENT - FAN GUARD FOR OIL COOLER
REV CHANGE BY DATE ECN
C
Modeled & Re-Drawn in Creo 2.0
T.B.B. 3/11/14 1572
D
Stand Weldment Replaced (23160 was 23038)
T.B.B. 1/19/16 1620
E
Pump 15240 Has Changed To Pump 16705 T.B.B. 12/14/16 1672
Cylinder 10448 Has Changed To Cylinder 16747
T.B.B. 1/16/17 1655
F
Cylinder 15928 Has Changed To 16750 Cylinder 10454 Has Changed To 16751
T.B.B. 2/3/17 1672
G
16845 REPLACED 16750 (Hyd. Cylinder) V.A.M. 8/11/17 1686
G
25695
DWG.
NO.
Hitch Frame & Components
