129
ELECTRICAL AND IGNITION
ELECTRIC START CIRCUIT
7
ELECTRIC START CIRCUIT
Start Circuit Diagram
+
5
10
9
1
2
3
4
6
11
13
16
3
14
7
1
2
3
5
6
7
8
12
13
14
15
16
9
10
11
7
6
5
4
3
2
1
8
9
17
16
15
14
13
12
11
10
13
12
11
10
17
16
15
14
FUSE
J1-B
J1-A
J2
4
B
A
+
POS
NEG
A
B
1
23
45
6
M
A
S
C
M
B
123456
8
13
15
9
12
17
34
33
32
31
30
29
28
27
26
006403
1. Marine battery 10. 26-pin J1-B EMM connector
2. RED wire (POS) 11. 34-pin J1-A EMM connector
3. BLACK wire (NEG) 12. Engine Management Module (EMM)
4. Starter solenoid 13. YELLOW/RED wire, start
5. Fuse (10 amp) 14. BLACK wire, start signal ground
6. RED/PURPLE wire 15. Neutral Safety Switch (remote control)
7. 6-pin connectors 16. RED starter motor cable
8. Ignition switch 17. Electric starter motor
9. PURPLE wire (switched B+)
