54
INSTALLATION AND PREDELIVERY
FUEL AND OIL PRIMING
Break-In Oiling
IMPORTANT: DO NOT add oil in the fuel tank
on Evinrude E-TEC models.
The Engine Management Module (EMM) auto-
matically supplies extra oil to the engine during
the first two hours of operation above 2000 RPM.
Follow these steps for outboard set-up:
• Use Evinrude Diagnostics software to make
sure the break-in program has been started.
Refer to Oil Control Settings on p. 98.
• The oil tank should be filled and the oil level
marked for reference.
IMPORTANT: The operator must monitor the oil
tank level to confirm oil consumption. This may
require several hours of operation above idle.
Oil Supply Priming
Use Evinrude Diagnostics software to make sure
the EMM is programmed for the type of oil being
used.
Start the outboard and use the oil priming function
in the software for a minimum of 90 seconds to
make sure the system is completely primed.
Observe oil flow through the oil distribution hoses.
Small bubbles are acceptable. Large bubbles
must be eliminated through continued priming.
IMPORTANT: All clear “blue” oil distribution
hoses on the powerhead should fill with oil as the
air is purged from the lines.
Repair any fuel or oil leaks.
The oiling system can also be primed using the
Self-Winterizing feature if diagnostics software is
not available. Refer to STORAGE on p. 77.
WARNING
Always use caution while working around
machinery with moving parts. The follow-
ing set-up procedures require running
tests that are performed with the out-
board’s motor cover removed.
Dynamic Tests Screen
1. Prime Oil button
006769
1
1. Oil distribution hoses 006767
1. Oil distribution hose
2. Small bubbles
3. Large bubbles
004398
1
1
1
32
