Evinrude 90 E-TEC - Specifications

45
 SPECIFICATIONS
SPECIFICATIONS
75, 90 Models
Displacement 79.1 cu. in. (1296 cc)
Engine Type In-line, 3 Cylinder, Two-Cycle,
E-TEC
Full Throttle Operating
Range
75 HP – 4500 to 5500 RPM
90 HP – 4500 to 5500 RPM
Power
(1)
(1) Rated following the standards of ICOMIA 28.83, ISO 3046 and NMMA.
75 HP – 75 HP (56 kw) @ 5000 RPM
90 HP – 90 HP (67.1 kw) @ 5000 RPM
Idle RPM in Gear
(2)
(2) Emission Control Information.
700 ± 50
Idle RPM in Neutral
(2)
600 ± 50
Ignition Timing
(2)
Not Adjustable
Emission Control System:
per SAE J1930
(2)
ECM, E-TEC (Engine Control Module, E-TEC )
Fuel Requirements
(2)
87 Pump Posted AKI (90 RON) – Refer to Oil and Fuel on
page 15
Oil – Lubricant
– Capacity
TC-W3 NMMA-certified oil or Evinrude/Johnson XD100 oil –
Refer to Oil and Fuel on page 15
2.65 qt. (2.5 l)
Warning Signals Controlled by the outboard’s
EMM
Battery, Minimum 640 CCA (785 MCA) 12 volt
Spark Plug
(2)
Refer to ECI Label
Fuses Refer to Fuse on page 29
Fuel Filter In-line Replaceable
Battery Charging 25-Amp, Fully Regulated
Gearcase – Lubricant
– Capacity
Evinrude Ultra-HPF™
L Models – 26 fl. oz. (770 ml)
X Models – 42 fl. oz. (1250 ml)
Power Trim/Tilt – Fluid
Capacity
21 fl. oz. (622 ml)
Propeller Refer to Propeller Selection on page 40
Weight L Models – 320 lbs. (145 kg)
X Models – 335 lbs. (152 kg)
Sound at Driver’s Ear
(LpA) ICOMIA 39.94
76.8 dB(A)
Transom Height L Models – 19 1/2 to 20 in. (495 to 508 mm)
X Models – 24 1/2 to 25 in. (622 to 635 mm)
