Evinrude E-TEC E115DPLSCR - Lower Cover Service; Lower Cover Removal; Lower Cover Installation

91
ENGINE COVER SERVICE
LOWER COVER SERVICE
4
LOWER COVER
SERVICE
Lower Cover Removal
Remove lower engine cover screws.
Loosen port side cover slightly, and disconnect
trim/tilt switch connector. Then, remove port and
starboard covers.
Lower Cover Installation
Install the lower engine covers and tighten all
screws to a torque of 24 to 36 in. lbs. (3 to 4 N·m).
Connect trim/tilt switch connector.
1. Lower cover screws 005242
005246
1
1
1. Lower cover screws 005242
005246
1
1
