DESCRIPCIÓN GENERAL DE LA MÁQUINA
1. Protección inferior de la hoja
2. Mordaza frontal giratoria
3. Mordaza trasera reposicionable
4. Protección superior de la hoja
5. Cadena de bloqueo inferior
6. Canal de extracción de polvo
7. Mecanismo de desenganche rápido
8. Cabeza de corte
9. Mango de corte
10. Enganche de bloqueo inferior
11. 4 tornillos de cabeza hueca
12. Botón del seguro del eje
13. Tornillo de bloqueo del mango palanca
14. Gatillo interruptor On/Off
15. Botón de bloqueo de seguridad
16. Escobillas de carbono
2
3
4
5
6
12
15
13
14
7
8
1
10
16
11
9
