DC POWER CONTROLLER – IP-POWER600-G2
IP-POWER600-G2 MAN REV. 11 Page 19 of 28
Table 3: Isolation Transformer Size and Secondary Voltages for a Single Power Controller
Module Type
Maximum
Required
DC Volts
Maximum
Required
DC Amps
Recommended
Input Voltage to G2
(VAC)
Minimum
Transformer KVA
rating
Fuse Size
for
Secondary
(Amps)
LX04 X&Z
53
6
220
0.6
4
LX10 X&Z
133
6
220
1.2
7
LX18 X&Z
240
6
330
2.2
9
LX24 X&Z
320
6
440
3.0
8
LX30 X&Z
400
6
440
3.5
10
LX45 X&Z
600
6
660
5.6
11
LX04HI
50
10
220
0.8
5
LX10HI
125
10
220
1.7
10
LX18HI
225
10
330
2.5
9
LX24HI
300
10
330
3.5
13
LX30HI
375
10
440
4.7
14
LX45HI
600
10
660
9
16
VNX25-2,
VNX28-2
600
6.6
660
5.6
11
VNX50-1,
VNX 50-2
600
13.2
660
10.5
20
VNX50-3,
VNX 55-2
600
13.2
660
10.5
20
VNX50-E,
VNX55-E
600
13.2
660
10.5
20
VNX50-EX,
VNX55-EX
600
13.2
660
10.5
20
VNX15CDIT-2
600
6.6
660
5.6
11
VNX30CDIT-2
600
13.2
660
10.5
20
VNX50-HH
600
10
660
9
16
MX30
27
2.5
220
0.2
1
MX60
53
2.5
220
0.3
2
MX125
106
2.5
220
0.5
3
MX250
213
2.5
330
0.9
4
MX500
426
2.5
550
1.7
4
In some cases, custom designed transformers will be required (example: 660 VAC secondaries are not
standard). The primary windings must be wound for the appropriate AC mains voltage.
