IONPURE
®
G2 DISPLAY BOARD – IP-POWERDSP-G2
IP-POWERDSP-G2MAN Rev 1 Page 22 of 25
Figure 22: MODULE OHMS&AMPS Screen
DIAGNOSTICS: this submenu provides the firmware revisions of the selected power
controller, the display and the results of the power controller’s self test routine.
Figure 23: DIAGNOSTICS Screen
DCPC rev: firmware revision of the power controller.
Display rev: firmware revision of the display board.
Self test: a G2 power controller monitors continuously the status of its power stage and
temperature sensor. The G2 display board reports in this screen the status of these
components using the following codes:
PASS: self test found no problems.
ERR1: power stage failure.
ERR2: temperature sensor failure.
If the self test routine outputs error codes ERR1 or ERR2, the “Unit status” alarm will
trigger. In this case, contact your Ionpure

products supplier for assistance.
