IONPURE
®
G2 DISPLAY BOARD – IP-POWERDSP-G2
IP-POWERDSP-G2MAN Rev 1 Page 7 of 25
2 Installation
2.1 Requirements
The G2 Display Board meets NEMA 4/IP65 requirements when properly installed. The unit is
intended to be mounted into an enclosed panel with the supplied gasket to provide a seal at the
panel cutout and it is secured from the back with the provided nuts.
The environmental limits for operation are 0 to 50 °C at up to 95% relative humidity
(non-condensing).
Consider the display’s dimensions shown in Figure 2 to select the proper size for the panel.
Figure 2: G2 Display Dimensions
All connections and settings in this section should be made without
energizing the power controller(s). Review other safety procedures prior to
working in the panel.
