Recorder
Description Selects the record channel to which the A/V material from the
hypermotion camera will be sent.
Values CAM A to CAM D
Default Values The default value is the last CAM defined in the channel
configuration (for ex. CAM C in a 3 IN 3 OUT configuration).
Remote mode
Description Specifies the camera elements controlled by the server.
Values • Hypermotion only:
The server controls only the hypermotion camera. An
additional remote is made available in the main menu of the
remote panel, since the hypermotion camera is considered
as an additional external camera.
• Hypermotion + LSM:
The server controls the hypermotion camera and one PGM
in exclusive mode.
Default value Hypermotion only
Port
Description Specifies on which port (RS422 or Lan PC) the commands
must be sent to the hypermotion camera, and possibly to the
PGM if you have selected ‘Hypermotion + LSM” in the Remote
Mode parameter.
Values The following values are possible:
• RS422 #2 to RS422 #6
• Lan PC
The port value is specific to the camera. See the camera-
specific section in the operational chapter .
Default value RS422 #6
USER MANUAL Multicam LSM 12.05 Hypermotion Cameras
2. Configuration 5
