EVS Multicam LSM User Manual

Protocol
Description Specifies the protocol type used for data transfer on the
selected port.
Values The following values are possible:
• TCP / UDP (when Port is set to Lan PC).
• ASCII / Sony 9-pin (when Port is set to one of the RS422).
The protocol value is specific to the camera. See the camera-
specific section in the operational chapter .
Default values • TCP (when Port is set to Lan PC).
• Sony 9-pin (when Port is set to one of the RS422).
IPAddress
Availability This setting is only available if the Port setting is set to Lan
PC.
Description Specifies the IP address of the PC LA N.
Values xxx.xxx.xxx.xxx
Default value 192.168.10.60
Dial Speed
Description Defines the multiplication factor applied to the jog value.
Values Range of values: 10x to 1000x (multiple of 10x)
Default value 10x
6 2. Configuration
EVS Broadcast Equipment SA Issue 12.05.A- May 2014
