Machine description – quick overview
Front view
14
099-007010-EW501
07.09.2016
Item
Symbol
Description 0
13
Connection socket, 14-pole
Remote control connection
14
Connection socket, “+” welding current
Connection for workpiece lead
15
Pilot arc button with signal light
Signal light off: pilot arc off
Signal light on: pilot arc lit
16
Toggle switch for no-power test
Simulation option for the set parameter values without welding
17
Cooling air inlet
18
Three-figure display
Display of the welding voltage
19
Machine control > see 3.3 chapter
20
Shielding gas connecting nipple (G1/4” left)
Connection to the welding torch or gas metering unit
21
Gas test push-button > see 4.1.7.3 chapter
22
Three-figure display
Display of the welding current
