Machine description – quick overview
Front view
099-005149-EW501
11.08.2016
15
Item
Symbol
Description 0
1
Lifting lug
2
VRD
Voltage reduction device (VRD) signal light
The VRD signal light is illuminated when the voltage reduction device is operating
without fault and the output voltage is reduced to a value specified in the relevant
standard (see technical data). The voltage reduction device is only active on VRD
machine versions.
3
Ready for operation signal light
Signal light on when the machine is switched on and ready for operation
4
Main switch, machine on/off
5
Carrying handle
6
Cooling air inlet
7
Wheels, guide castors
8
Coolant tank
9
Coolant tank cap
10
Automatic cut-out of coolant pump key button
press to reset a triggered fuse
11
Connection socket, “-” welding current
12
Connection socket, “+” welding current
