Chapter 3 Calibration
3-1 4 Wire Load Cell Connection
PIN
Name
1
E+
2
E-
3
S+
4
S-
5
SEN-
6
SEN+
PIN1: E+
PIN6: SEN+
PIN4: S-
PIN5: SEN-
PIN2: E-
PIN3: S+
