MODBUS Data Address Table II (For Hitech and Pro-face Human Machine Interface)
Data Register
Bit I/O
Bit I/O
Function Code 03 (Read )
Function Code 01 (Read)
Function Code 05 and 15 (Write)
Modbus
SCALE
Modbus
SCALE Output
Modbus
SCALE Input
40005 ~ 40006
As display value
00001
Stable status
01001
Zero
00002
Zero status
01002
Function Code 06 and 16 (Write)
00003
Gross
01003
Tare
41001 ~ 41002
Pre-tare value
00004
Net
01004
Clear tare
41015 ~ 41016
LO limit value
00060
Hi
41019 ~ 41020
HI limit value
00061
Ok
00062
Lo
Appendix 4 7-Segment Display Characters
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
V
W
X
Y
Z
