Excell FDH3-W User Manual

EXCELL PRECISION CO., LTD.
0201813X ZSME300000366
25
Appendix 2 Load Cell PIN
Load Cell
Load Cell cable
shield
EXC+
SIG+
EXC-
SIG-
Appendix 3 MODBUS Data Address Table
MODBUS Data Address Table I
Data Register
Bit I/O
Bit I/O
Function Code 03 (Read )
Function Code 01 (Read)
Function Code 05 and 15 (Write)
Modbus
SCALE
Modbus
SCALE Output
Modbus
SCALE Input
40004 ~ 40005
As display value
00000
Stable status
01000
Zero
00001
Zero status
01001
Function Code 06 and 16 (Write)
00002
Gross
01002
Tare
41000 ~ 41001
Pre-tare value
00003
Net
01003
Clear tare
41014 ~ 41015
LO limit value
00059
Hi
41018 ~ 41019
HI limit value
00060
Ok
00061
Lo
1
EXC+
2
EXC -
3
SIG+
4
SIG -
5
GND
5-pin female
connector
Weighing scale
(AW, HW, FD, RW, TW)
