EXCELL PRECISION CO., LTD.
0201813X ZSME300000366
1-4 Power Description
6V 4Ah Rechargeable battery
Power consumption with
1X350Ω load cell
Single display with
backlight
Dual display with
backlight
Low Power Alarm
Please note when the ( ) symbol keeps flashing on the left down corner of the display,
the batteries should be recharged.
When the low battery warning symbol shows up, scale is turned off automatically after 5~10
hours if it is used without backlight (1~2 hours if it is used with backlight). Then scale must be
fully recharged, before operating again.
Please recharge at once when the symbol shows in order to keep the weight accuracy.
1-5 Error Messages
oL Weight exceeds 9d of maximum capacity. (d=division)
E1 Zero value after power on is over +10% FS.
E2 Zero value after power on is less than -10% FS.
E4
Unstable zero return, unstable over 10 sec. Press to leave E4.
E6 Zero is too high when calibrating. (over internal value 350,000)
E7 Zero is too low when calibrating. (under internal value 80,000)
E10 The scale is not in level status.(only available with level detector equipment.)
- - - - - - For weight < -20d without tare or pretare device in operation.
E10 Level Switch (option)
Make JP102 on PCB board of AW, HW, FD, RW, TW) to be open circuited. Then connect
signal to CN101 on PCB of AW, HW, FD, RW, TW). When CN101 is open circuited, display
shows E10 after 2 seconds and all keys stop working in the mean time. When CN101 is
short circuited, display resumes and can continue weighing. If you do not need level switch,
make JP102 short circuited.
