Technical Specifications
68 FPM/FLS/FOT-600
FLS-600
FLS-600
SPECIFICATIONS
a
Model 12D 23BL 234BL 235BL
Central wavelength (nm) 850 ± 25
1300 +50/–10
1310 ± 20
1550 ± 20
1310 ± 20
1550 ± 20
1625 ± 15
1310 ± 20
1490 ± 10
1550 ± 20
Spectral width
b
(nm) 50/135 )5 )5 )5
Output power (dBm) *–20/*–20 (62.5/125 μm) *1/*1 *1/*–3/*–5 *1/*–4.5/*–3
Power stability
c
(dB)
15 min
8 h
±0.05
±0.1
±0.03
±0.1
±0.03
±0.1
±0.03
±0.1
Auto-switching Yes Yes Yes Yes
Tone generation 270 Hz, 1 kHz, 2 kHz 270 Hz, 1 kHz, 2 kHz 270 Hz, 1 kHz, 2 kHz 270 Hz, 1 kHz, 2 kHz
Battery life (hours) (typical in Auto mode) 50 50 50 50
Warranty (years) 3 3 3 3
GENERAL SPECIFICATIONS
a
Size (H x W x D) 190 mm x 100 mm x 62 mm (7
1
/2 in x 4 in x 2
1
/2 in)
Weight 0.48 kg (1.1 lb)
Temperature
operating
storage
—10 °C to 50 °C
—40 °C to 70 °C
(14 °F to 122 °F)
(—40 °F to 158 °F)
Relative humidity 0 % to 95 % non-condensing
