MaxTester 11
4 Physical Interfaces and LEDs
This section describes all connectors (ports) and LEDs available on the
MAX-800 Series.
MAX-860 and MAX-860G Models
CAUTION
To prevent exceeding the maximum input/output power level,
please refer to this product’s technical specifications at
www.exfo.com.
SFP+
P2
1
1. Laser radiation emitted from this port when LASER LED is on.
SFP+
P1
1
RJ45 P1
DUPLEX
LINK/ACT
LINK/RX
LASER
LINK/RX
LASER
