Test Results
MaxTester 285
Summary
Traffic / Traffic Ethernet
Note: The Traffic statistics are available for Smart Loopback and Through Mode
test applications. See Traffic - Ethernet on page 302 for more information.
RX Frequency
Note: RX Frequency is available for Through Mode test application on both ports
for rates up to 10G LAN. Not available for a port using an active copper SFP.
Frequency (GHz) indicates the frequency of the input signal.
Offset (ppm) indicates the frequency offset between the standard rate
specification and the rate at the input signal.
Note: For both Frequency and Offset the following background colors are used.
Background color Description
Green The frequency is in range.
Red The frequency is out-of-range or LOC Lane. LOC is also
displayed.
Gray Pending state.
