Exmark Frontrunner 4500-341 - Auxiliary Hydraulic Group

AUXILIARY HYDRAULIC GROUP
14
Item Part No. Description Qty.
1V 109-2853 Asm, Hydraulic Power Unit ....................1
2 109-2015 Hose, Hydraulic......................................1
3 109-2016 Hose, Hydraulic......................................1
4 109-0760 Adapter, 90°...........................................2
109-1284 O-Ring (37° Flare #4).............................1
1-603923 O-Ring (SAE #4)....................................1
5 323-4 Screw, HH 3/8-16 x 5/8 ..........................2
6 98-5975 Washer, Spring Disc 3/8 ........................2
7 109-2812 Asm, Cylinder W/Decal ..........................1
109-2856 Kit, Hyd Cylinder Seal ............................1
Item Part No. Description Qty.
8 109-2663 Terminal, Ring 5/16 ............................... 2
9 109-1180 Pin, Cylinder Mount ............................... 1
10 109-2377 Decal, High Pressure Oil ....................... 1
11 1-806005 Hairpin, Cotter ....................................... 1
12 321-4 Screw, HH 1/4-20 x 3/4.......................... 1
13 3296-42 Nut, Nyloc 1/4-20................................... 1
14 103-1193 Clip, Loom ............................................. 2
15 109-2017 Adapter, Straight ................................... 2
109-1284 O-Ring (37° Flare #4) ............................ 1
1-603923 O-Ring (SAE #4).................................... 1
V Includes item #8.
