HYDRAULIC GROUP
15
Item Part No. Description Qty.
1 1-413088 Spacer ...................................................1
2 32128-43 Nut, Whizlock 3/8-16..............................4
3 109-4076 Sheave, Idler..........................................1
4 1-805004 Washer, Lock 1/4 Heavy........................2
5 103-2739 Key, 5mm x 5mm x 32mm .....................2
6V 30-1710 Setscrew, 5/16-18 x 1 ............................4
7 98-5975 Washer, Spring Disc 3/8 ........................1
8 103-1828 Adapter, Running Tee............................3
1-603921 O-Ring (SAE #6)....................................1
9 109-0582 Asm, Hydraulic Reservoir W/Decal ........1
10 103-7615 Asm, Cap W/Gasket ..............................1
11 103-1949 Gasket, Reservoir Cap...........................1
12 103-1988 Clamp, Hose 11/16 ................................ 6
13 103-2146 Element Hydraulic Oil Filter....................1
14 103-2155 Adapter, 90°...........................................2
15 1-603990 Adapter, Straight .................................... 3
103-1020 O-Ring (37° Flare #6).............................1
1-603920 O-Ring (SAE #8)....................................1
16 103-2259 Head, Filter ............................................ 1
17 103-2916 Guard, Top.............................................2
18 116-0133 Spring, Extension...................................1
19 103-3504 Bearing, Spherical..................................2
20 103-3506 Seal, Single Lip...................................... 2
21 103-6409 Kit, Pump Idler ....................................... 1
22 1-303287 Tie, Cable 5 1/2 (Small) ......................... 1
23 103-8011 Spacer, Spring .......................................1
24 103-8357 Pump, Hydro W/Fan (LH) ......................1
25 103-8358 Pump, Hydro W/Fan (RH) ......................1
26 106-7159 O-Ring ................................................... 2
27 109-5949-03 Arm, Idler ...............................................1
28 109-0816 Belt ........................................................1
29 109-0899 Hose, Hydraulic...................................... 1
Item Part No. Description Qty.
30 109-0900 Hose, Hydraulic ..................................... 1
31 109-0901 Hose, Hydraulic ..................................... 1
32 109-0902 Hose, Hydraulic ..................................... 1
33 109-1008 Hose, Case Drain .................................. 2
34 109-1009 Hose, Hydraulic ..................................... 1
35 109-1010 Hose, Hydraulic ..................................... 1
36O 103-9519 Motor, Wheel (RH)................................. 1
37O 103-9520 Motor, Wheel (LH) ................................. 1
38 103-2153 Adapter, 90° .......................................... 2
103-1020 O-Ring (37° Flare #6) ............................ 1
1-603920 O-Ring (SAE #8).................................... 1
39 109-2202 Sheave .................................................. 2
40 109-4644 Hose, Hydraulic ..................................... 1
41 109-4645 Hose, Hydraulic ..................................... 1
42 302-40 Zerk, 90° 1/4-28..................................... 1
43 321-3 Screw, HH 1/4-20 x 5/8.......................... 2
44 321-6 Screw, HH 1/4-20 x 1............................. 2
45 323-16 Screw, HH 3/8-16 x 4............................. 1
46 323-7 Screw, HH 3/8-16 x 1 1/4....................... 7
47 325-10 Screw, HH 1/2-13 x 2 1/2....................... 8
48 3231-10 Bolt, Carriage 3/8-16 x 3 ........................ 1
49 3231-6 Bolt, Carriage 3/8-16 x 2 ........................ 1
50 3256-22 Washer, 1/4 SAE................................... 2
51 3256-26 Washer, 1/2 SAE................................... 8
52 3256-4 Washer, 3/8 Std.....................................
As
Req’d.
53 3290-357 Nut, Whizlock 3/8-16 ............................. 6
54 32120-10 Ring, Retaining ...................................... 2
55 32128-33 Nut, Whizlock 1/4-20 ............................. 2
56 32128-49 Nut, Whizlock 1/2-13 ............................. 8
57 116-0404 Decal, Hydraulic Tank............................ 1
58 3256-24 Washer.................................................. 1
Exmark black touch up spray paint – gloss black.
V Use Prolock, Nut Type (P/N 1-840022, .5ml tube) on setscrews, items #6.
O Wheel Motor Service Kits
Part No. Description Qty.
103-9762 Kit, Seal ....................................................... 1
103-9763 Handle, Actuating......................................... 1
103-9764 Clip, Retaining.............................................. 1
103-9765 Nut, Hex Toplock 1-20UNEF-2B .................. 1
103-4242 Asm, Wheel Hub W/Studs ........................... 1
103-7447 Stud, Wheel 1/2-20 x 1/2.............................. 4
Hydro Pump Service Kits
Part No. Description Qty.
109-2863 Bearing, Input Shaft PR ............................... 1
109-2864 Kit, Cylinder Block 16CC PR........................ 1
109-2865 Bearing, Thrust PR ...................................... 1
109-2866 Kit, Overhaul Seal PR.................................. 1
109-2867 Plate, Valve PR............................................ 1
103-7488 Fan, Pump Cooling ...................................... 1
103-7489 Guard, Pump Fan ........................................ 1
To Next Page
