Exmark Frontrunner 4500-341 - Main Frame Group

MAIN FRAME GROUP
3
Item
Part No.
DESCRIPTION Qty.
1 1-323142 Nut, Push 1/2 ......................................... 2
2 109-2365 Bumper ..................................................4
3 109-3478 Asm, Wheel & Tire (RH) ........................1
109-3156 Wheel ....................................................1
103-6771 Tire, 24x12-12 4 Ply ...............................1
4 1-633859 Frame, Seat ...........................................1
5 1-803035 Rivet 3/16 x 1/4 ......................................9
6 98-5975 Washer, Spring Disc 3/8 ........................8
7 103-0291 Cushion, Armrest LH..............................1
8 103-0292 Cushion, Armrest RH .............................1
9 103-2882 Decal, Exmark Logo...............................2
10 103-3520 Seat, Back .............................................1
11Q 103-4553 Asm, ROPS Fold Pin .............................2
12 1-543401 Spacer, Seat Track ................................ 2
13 103-8383 Screw, HWH 1/4-20 x 3/4 Taptite...........11
14 103-5161 Link, Seat Stop ......................................2
15 103-6761 Asm, Seat Frame...................................1
16 103-6765-03 Latch, Seat ............................................1
17 32128-33 Nut, Whizlock 1/4-20..............................2
18 9264964 Bolt, HWH 5/16-18 x 3/4 Tap ................. 4
19 32128-20 Nut, Whizlock 5/16-18............................ 16
20 3296-73 Nut, Nyloc 1/4-20 ...................................2
21 103-8316 Spring ....................................................1
22 103-8826 Link, Lower Seat Stop............................2
23 103-6761 Plate, Seat Mount ..................................1
24 1-633080 Bushing..................................................2
25X 109-2817 Kit, ROPS .............................................. 1
26 107-2102 Decals, Warning ....................................1
Item
Part No.
DESCRIPTION Qty.
27 107-3155 Cotter, Hair Pin Double Loop ................. 2
28 109-3633-03 Spacer, Seat Mount ............................... 2
29 3296-7 Nut, Nyloc 7/16-20................................. 2
30 109-0768 Skirt, Rubber.......................................... 1
31 109-3547 Asm, Front Console W/Decal ................ 1
32 109-2008 Cushion, Seat Bottom/W Switch............ 1
33 109-2009 Grp, Seat Track ..................................... 1
34O 109-2005 Asm, Seat W/Decal ............................... 1
35 109-2360 Decal, Top Console ............................... 1
36 3256-14 Washer, #10 Std.................................... 9
37 3296-39 Nut, Nyloc 3/8-16................................... 4
38 116-1003 Decal, Service Aid ................................. 1
39 110-0883 Kit, Seatbelt ........................................... 1
40 242-50 Nut, Lug 1/2-20...................................... 8
41 283-69 Pin, Clevis 1/2 x 3 1/2............................ 2
42 322-5 Screw, HH 5/16-18 x 1........................... 8
43 322-7 Screw, HH 5/16-18 x 1 1/2 ..................... 2
44 323-6 Screw, HH 3/8-16 x 1............................. 2
45 323-8 Screw, HH 3/8-16 x 1 1/2....................... 8
46 323-9 Screw, HH 3/8-16 x 1 3/4....................... 2
47 3212-4 Screw, HH 7/16-20 x 1........................... 2
48 3296-29 Nut, Nyloc 5/16-18................................. 4
49 3256-3 Washer, 5/16 Std................................... 6
50 3256-4 Washer, 3/8 Std..................................... 1
51 3290-357 Nut, Whizlock 3/8-16 ............................. 8
52 109-3479 Asm, Wheel & Tire (LH)......................... 1
109-3156 Wheel .................................................... 1
103-6771 Tire, 24x12-12 4 Ply............................... 1
Exmark black touch up spray paint – Gloss black
Q Includes ROPS fold pin plus hairpin, item #27.
X Rollover protection frame is serviced as a complete assembly only. Includes complete ROPS frame, mounting
hardware, fold pivot and locking hardware, seat frame assembly item #15 and seat belt assembly item #39.
O Includes armrests and seat back decal. Does not include seat belt or tracks.
 Does not include item #19 or #48.
