MAIN FRAME GROUP (cont.)
5
Item
Part No.
DESCRIPTION
Qty.
1 1-513747 Decal, Battery ........................................1
2 1-523157 Washer ..................................................4
3 1-643189 Keeper, Rubber Latch ............................2
4 1-643339 Belt Routing, Decal ................................1
5 1-806003 Hairpin, Cotter........................................2
6 1-806005 Hairpin, Cotter........................................1
7 1-808285 Pin, Clevis 3/8 x 1 1/8 ............................2
8 5-0652 Spacer ...................................................4
9 93-2699 Pin .........................................................2
10 98-4361 Decal, Warning ...................................... 2
11 98-5954 Decal, Danger........................................1
12 100-1663 Pin .........................................................2
13 103-1166 Tube, Pump Link Spacer ....................... 2
14 32151-36 Ring, Retaining ......................................4
15 103-3270 Decal, 3750 RPM...................................1
16 103-5881 Decal, Guard.......................................... 2
17 103-7218 Decal, Pump Fan Warning.....................1
18 109-6069 Asm, Frame W/Decals...........................1
19 103-9727 Latch, Hitch............................................2
20 107-2112 Decal, Danger........................................1
21 107-8042 Bumper, Rubber.....................................2
22 109-0075 Asm, Hitch ............................................. 1
23 109-0080-03 Wld, Hitch ..............................................1
24 109-0325 Pin, Full Fold.......................................... 1
25 109-0411 Spring ....................................................2
26 109-0435 Bushing..................................................4
27 109-0450 Asm, Spring ........................................... 2
28 109-2772 Asm, Floorpan W/Decal.........................1
29 109-2773 Asm, Spring Bellcrank W/Decal (RH)..... 1
30 109-2774 Asm, Spring Bellcrank W/Decal (LH) .....1
Item
Part No.
DESCRIPTION
Qty.
31 109-0634 Wld, Spring Anchor................................ 4
32 109-1256-03 Arm, Pivot.............................................. 2
33 109-1257-03 Hook, Hood............................................ 2
34 109-3197 Hood, W/Decal ...................................... 1
35 109-2857 Asm, Hood............................................. 1
36 109-6070 Asm, Hood Support W/Decals .............. 1
37 109-2004 Roller, Lock Lever.................................. 2
38 32128-20 Nut, Whizlock 5/16-18 ........................... 4
39 109-2355 Decal, Spring Loaded ............................ 2
40 109-2356 Decal, Motion Control ............................ 1
41 109-2357 Decal, Motion Cntl/Park Brake............... 1
42 109-2396 Decal, Pump Drive Release................... 1
43 302-19 Zerk, 1/4-28 Str...................................... 2
44 322-3 Screw, HH 5/16-18 x 3/4........................ 4
45 322-4 Screw, HH 5/16-18 x 7/8........................ 8
46 323-11 Screw, HH 3/8-16 x 2 1/4....................... 2
47 323-8 Screw, HH 3/8-16 x 1 1/2....................... 2
48 325-18 Screw, HH 1/2-13 x 4 1/2....................... 2
49 32120-47 Ring, Retaining ...................................... 4
50 3256-23 Washer, 5/16 SAE ................................. 20
51 3256-24 Washer, 3/8 SAE................................... 4
52 3256-26 Washer, 1/2 SAE................................... 8
53 3256-27 Washer, 5/8 SAE................................... 2
54 3269-24 Rivet ...................................................... 4
55 3296-23 Nut, Nyloc 1/2-13................................... 2
56 3296-29 Nut, Nyloc 5/16-18................................. 8
57 3296-39 Nut, Nyloc 3/8-16................................... 4
58 32120-19 E-Ring ................................................... 2
59 109-2114 Decal, FrontRunner ............................... 1
Exmark red touch up paint (spray paint - P/N 1-850337 - .6 oz liquid bottle - P/N 103-9140).
Exmark black touch up spray paint – Gloss black
