Exmark LAZER Z S-SERIES User Manual

Specications
–Separatelevers,oneachsideoftheconsole,
controlspeedanddirectionoftravelofthe
respectivedrivewheels.
–Steeringiscontrolledbyvaryingtheposition
oftheleversrelativetoeachother.
–Movingmotioncontrolleversoutward(in
slots)locksthedrivesysteminneutral.
•PTOEngagementSwitch:Engageselectricclutch
(todrivebelt)whichengagesmowerblades.
•ParkingBrakeLever:Engagesparkingbrake.
•ParkingBrakeReleaseButton:Releasesparking
brake.
•DeckHeightAdjustmentLever:Setscutting
heighttodesiredposition.
•DeckLiftPedal:Footpedalthatliftsdeck.
•TransportLock:
–Latchingposition:Automaticallylatchesat
thetransportposition.
–Unlatchingposition:Deckdoesnotlatchat
thetransportposition.
Seat
•Type:Standardseatwithhighback,extra
widefoampaddedseatcushionwithinternal
suspension,thickbolstering,armrests,integral
safetyswitch.
Optionalseataccessoriesforunitswithstandard
seats:
–Customridesuspensionsystemtoenhance
StandardSeat.Addsapproximately3inches
(7.6cm)toseatheight.
–Deluxesuspensionseatwithhighback,
(dampened,adjustablespringsuspension),
armrests,andintegralsafetyswitch.Adds
approximately1/2inch(1.3cm)toseatheight.
–SeatIsolationSystemforreducedvibration,
toenhancerideofstandardseat,standardseat
withCustomRideSeatSuspensionorDeluxe
SuspensionSeat.Addsapproximately1inch
(2.5cm)toseatheight.
•Mounting:Adjustableforeandaftonseattracks.
•Armrests:
–Standardseat:foampaddedadjustableip-up
armrests.
–Suspensionseat:moldedadjustableip-up
armrests.
•SeatSafetySwitch:
Integratedseatswitch.Timedelayseatswitch
eliminatesroughgroundcut-outs.
HydrostaticGroundDriveSystem
•Twounitizedhydrostatictransmissions:
12ccParkeraxialpistonpump
240ccParkergerolermotor
•HydraulicOilType:ExmarkPremiumHydroOil.
•HydraulicOilCapacity:52oz(1.5L)perside
•HydraulicFilter:P/N116-0164
•Speeds:
–0-10mph(16.1km/hr)forward.
–0-5.5mph(8.9km/hr)reverse.
•Drivewheelreleasevalvesallowmachinetobe
movedwhenengineisnotrunning.
Tires&Wheels
Drive
Pneumatic(Airlled)
DeckSize
48&5260&72
Quantity
22
Tread
TurfMasterTurfMaster
Size24x9.50-1224x12.00-12
PlyRating
44
Pressure
13psi(90kPa)13psi(90kPa)
FrontCaster
Semi-Pneumatic
DeckSize
48,52,&
60(except
LZS27KC604)
72&
LZS27KC604
Quantity
22
Tread
SmoothSmooth
Size13x5.00-613x6.50-6
PlyRating
44
Pressure
N/AN/A
CuttingDeck
•CuttingWidth:
17

Exmark LAZER Z S-SERIES Specifications

General

Engine Brand	Kawasaki
Cutting Width	60 inches
Transmission	Hydro-Drive
Deck Construction	Fabricated
Deck Material	10-gauge steel
Turning Radius	Zero-turn
Speed	10 mph
