Maintenance
Adjustments
Note:DisengagePTO,shutoffengine,waitfor
allmovingpartstostop,engageparkingbrake,and
removekeybeforeservicing,cleaning,ormakingany
adjustmentstotheunit.
CAUTION
Raisingthemowerdeckforserviceor
maintenancerelyingsolelyonmechanical
orhydraulicjackscouldbedangerous.The
mechanicalorhydraulicjacksmaynotbeenough
supportormaymalfunctionallowingtheunitto
fall,whichcouldcauseinjury.
DoNotrelysolelyonmechanicalorhydraulic
jacksforsupport.Useadequatejackstandsor
equivalentsupport.
DeckLeveling
1.Positionthemoweronaatsurface.
2.Stopengine,waitforallmovingpartstostop,and
removekey.Engageparkingbrake.
3.Checkthetirepressureinthedrivetires.Proper
inationpressurefortiresis13psi(90kPa).
Adjustifnecessary.
4.Positionthetransportlockinthelatching
position.
5.Pushthefootpedalallthewayforwardandthe
deckwilllatchatthe51/2inch(14cm)transport
position(Figure26).
Figure26
1.Footlever3.Transportlock
2.Heightofcutpin
6.Inserttheheightadjustmentpinintothe3inch
(7.6cm)cuttingheightlocation.
7.Releasethetransportlockandallowthedeckto
lowertothecuttingheight.
8.Raisethedischargedeector.
9.Measurefromthelevelsurfacetothefronttipof
thecenterblade.Themeasurementshouldread
3inches(7.6mm).
Note:Inmostconditions,thebackbladetip
shouldbeadjusted1/4inch(6.4mm)higherthan
thefront.
Figure27
1.31/4inches(8.3cm)4.3inches(7.6cm)
2.Backbladetip
5.Levelsurface
3.Frontbladetip
10.Loosenthejamnutsonthetopofeachdeck
link.Finetunetheadjusteronthefrontdecklift
assemblybyturningittoget3inch(7.6mm)
height(seeFigure28).
Toincreasetheheight,turntheadjusterclockwise;
todecrease,turncounterclockwise.
40

Exmark LAZER Z S-SERIES Specifications

General

Engine Brand	Kawasaki
Cutting Width	60 inches
Transmission	Hydro-Drive
Deck Construction	Fabricated
Deck Material	10-gauge steel
Turning Radius	Zero-turn
Speed	10 mph
