Exmark QSS708GEM42200 - Torque Requirements; Product Overview

ProductOverview
WheelBase:(CenterofCasterTireto
CenterofDriveTire)
42InchDeck50InchDeck
52.5inches(133cm)50.5inches(128cm)
CurbWeight:
42inchDeck50inchDeck
645lb(293kg)713lb(323kg)
TorqueRequirements
BoltLocation
Torque
SpindlePulleyNut35-65ft-lb(47-88N-m)
BladeMountingBolt35-65ft-lb(47-88N-m)
EngineMountingBolts
330-400in-lb(37-45N-m)
WheelLugNuts
70-90ft-lb(95-122N-m)
ClutchMounting
Bolt(securedwith
threadlocker)
50-60ft-lb(68-81N-m)
ProductOverview
Figure3
1.Frontcasterwheel
8.Controlpanel
2.Anti-scalproller9.Engine
3.Traction-controlpedal
10.Seat
4.Dischargedeector
11.Fueltank
5.Deckheightadjustment
lever
12.Steeringwheel
6.SmartPark™switch13.KeyChoice
®
control
7.Reardrivewheel14.Mowerdeck
