Expobar ELEN Service Manual

10
Elen
R
Elen Display Control 3GR
TECHNICAL SPECIFICATIONS
SPECIFICATIONS
Elen 3gR
Display control 3 Boilers display control
Machine model, Standard - -
Machine model, Take Away - -
Steam wand 2 units 2 units
Hot water outlet 1 unit 1 unit
Temperature control PID regulation PID regulation
Temperature control by group No Yes
Programmed via display Yes Yes
Dispensing system for tall cups Optional Optional
Energy saving mode Yes Yes
Height, width, depth (mm) 530, 980, 590 530, 980, 590
Boiler volume (L) 17.5 17.5 + 1.5 + 1.5 + 1.5
Power supply
400V 2N~ 4290W
50/60 Hz
-
400V 3N~ 6290W
50/60 Hz
400V 3N~ 6290W
50/60 Hz
220-240V 3~ 4290W
50/60 Hz
220-240V 3~ 4290W
50/60 Hz
Water connection Female 3/8" thread Female 3/8" thread
Machine weight (kg) 51.90 60.70
Steam boiler operating pressure Between 0.8 and 1.2 bar Between 0.8 and 1.2 bar
Ambient noise < 70 db < 70 db
