Expobar ELEN Service Manual

41
Elen
R
Elen Display Control 2Gr
Machine Code:
EBAE-D41B-12AE (Standard)
EBBE-D41B-22AE (Take Away)
ELECTRICAL DIAgRAMS
(220-240V 1N~ 3200W)
M. PN: C60000016
C.V.1 PN: C60100045
S.N.
PN: C60100040
Ev.A.I.
PN: C60000100
Ev.G
.1
PN: C60000112
Ev.G.2
PN: C60000112
C.V.2 PN: C60100045
Ev.C.C. PN: C60000105
Heating-ON/OFF
STEAM-AUX
GR 3GR 2
GR 1
Out
+
Cn 3
Cn 1
DISPLAY LCD
OUT 3 OUT 2
OUT 1
SLiv
+(Vcc)
Gnd
EVTEA
EVFILL
EVGR3 EVGR2
EVGR1
PUMP
COMMON MAIN SUPPLY
S:\Drawing Files\esquemas electricos\3D5 DELUXE\e-91.5_XCI5_CONTROL DISPLAY 3D5 LUX ELEN-ROSETTA_2015.dft
MAXI CONTROL DISPLAY 2GRMAXI CONTROL DISPLAY 2GRMAXI CONTROL DISPLAY 2GR
C.E.L
.
PN: C60100034
S.T.C
PN: C60100076
8x2
8x2
2x8
D.G.
PN: C60101050
B.G.1
PN: C60101500
B.G.2
PN: C60101500
M
B.G. TOUCHPAD G10/ELEN/MARKUS/MONROC 3D5 C.E.L 3D5 LUX CONTROL BOARD C.V. FLOWMETER D.G. DISPLAY G10/ELEN/MARKUS 3D5 LUX Ev.A.I. HOT WATER SOLENOID VALVE Ev.C.C. BOILER WATER INLET SOLENOID VALVE Ev.G. GROUP SOLENOID VALVE M. MOTOR-ROTATORY VANE PUMP P.E. BREWING SWITCH S.N. WATER LEVEL PROBE S.T.C. BOILER TEMPERATURE PROBE
R.E.C.
(3-32V)
PN: C60800101
+
-
R.E. PN: C38027000
P. PN: C60901001
I.G
PN: C60900001
N - O
L1 - R
G
S.E
t° t°
S.E PN: C60103025
t°
T.S.3P
PN: C10200150
ABREV. DESCRIPTION
G. GROUND I.G. POWER SWITCH (ROTARY TYPE) L. PHASE LINE N. NEUTRAL P. HEATING ELEMENT SI GNAL DEVICE R.E. HEATING ELEMENT R.E.C. SOLID STATIC RELAY DC S.E EMI SUPPRESSION CAPACITOR T.S.1P THERMAL CUT-OUT 1 POLE WITCH BULB. T.S.3P THERMAL CUT-OUT 3 POLE WITCH BULB.
