Extech Instruments 96VFL User Manual

VFL Series User Manual v2.0 10/20
35
Type T range
-454 to 752
o
F (-270 to 400
o
C)
Type E range
-58 to 1382
o
F (-50 to 750
o
C)
Type R range
32 to 3182
o
F (0 to 1750
o
C)
Type S range
32 to 3182
o
F (0 to 1750
o
C)
Type N range
-58 to 2372
o
F (-50 to 1300
o
C)
Type C range
-58 to 3272
o
F (-50 to 1800
o
C)
17.3 RTD Input Specifications
RTD types
Platinum 100 ohms (DIN and JIS)
RTD ranges
(DIN) -328 ~ 1652
o
F (-200 ~ 850
o
C)
(JIS) -328 ~ 1202
o
F (-200 ~ 650
o
C)
Break protection
Up- and down-scale
Lead wire effect
0.015
o
/ Ohm
Repeatability
0.2
o
C
17.4 Analog (Linear) Input Specifications
Current Input
4 to 20mA DC (2.7 ohms input impedance)
Voltage Input
1 to 5V DC (> 10M ohms input impedance)
Display range
-1999 to 9999 digits
Repeatability
+/- 1 digit
17.5 Relay and DC Trigger Control Output Specifications
Relay output
SPST, mechanical, dry contact relay
Rated for 5 Amps @ 110V AC or 24VDC (Resistive Loads)
DC trigger (pulse) output
24V DC (DC drive for external SSR)
ON: 24V DC typical, 29V DC max; OFF: 0.3V DC max
Control actions
Indirect (heating) and Direct acting (cooling)
Control types
ON/OFF control with Hysteresis
Time proportioning control (for relay/pulsed DC)
Standard proportional output (analog output)
Automatic tuning
Determines proportional band % and integral/derivative times
