CHAPTER 21
PAGE 7
PAGE DATE: 1. August 2014
MAINTENANCE MANUAL EXTRA 330/SC
4 Remove clamp sheet (9, 11) attachment bolts on the fire-
wall.
5 Loosen hose clamp (8).
6 Mark Bowden cable (2) routing and remove the attachment
self-clinching plastic straps (3).
7 Remove attachment nut and washer (5) of the control handle
(1).
8 Pull the control handle (1) with the complete Bowden cable
(2) aft to remove from aircraft. Secure label plate (6), clamp
sheets (9, 11) and attachment nut and washer (5).
Installation
Refer to Figure 3.
1 Thread the Bowden cable (2) end through the respective at-
tachment tube (4).
2 Thread the attachment nut and washer (5) on the Bowden
cable.
3 Ensure nut (7) is fastened.
4 Place label plate (6) and align.
5 Attach the control handle (1) and the label plate (6) by means
of its attachment nut and washer (5).
6 Position the Bowden cable (2) along the prior marked rout-
ing.
7 Fasten the Bowden cable (2) with self-clinching plastic
straps (3) in place.
8 Thread the Bowden cable end through the hose clamp (8).
9 Thread the Bowden cable through the firewall.
10 Renew the sealing of the clamp sheets (9, 11). Use PRC
812 sealant (refer to Chapter 20-10-10).
N O T E Ensure distance of cable housing end to clamp sheet is
50 mm (refer to detail C of figure 3) when installing
the clamp sheets.
11 Install the clamp sheets (9, 11).
