CHAPTER 21
PAGE 8
PAGE DATE: 1. August 2014
MAINTENANCE MANUAL EXTRA 330/SC
12 Fasten the hose clamp (8).
13 Ensure inlet box actuator is in closed position.
14 Push control handle (1) to the full forward position. Then
pull aft 5 mm (refer to detail A of figure 3).
15 Install the Bowden cable to the inlet box actuator (10).
16 Check full travel.
Rigging
Refer to Figure 3.
1 Loosen Bowden cable attachment bolt on the inlet box ac-
tuator (10).
2 Place inlet box actuator (10) to the closed position.
3 Adjust main handle (1) to the full forward minus 5 mm po-
sition (refer to detail A of Figure 3).
4 Fasten Bowden cable attachment bolt on the inlet box ac-
tuator (10).
5 Check full travel.
