CHAPTER 27
PAGE 18
MAINTENANCE MANUAL EXTRA 300/SC
PAGE DATE: 1. August 2014
2 Loosen the hinge bolts and the ground bonding leads and
remove the bolts.
3 Install in reverse sequence of removal. Observe the second
Note of Chapter 27-00-00 and Figure 4.
Rigging
Inspect the control cables, the fairleads and the bottom hinge
assembly (with the travel stop plate) for signs of wear or
damage before beginning any adjustments. Replace parts if
necessary.
1 Secure the rudder pedals following step 2 and 3 of Chapter
27-20-03.
2 Check if the rudder is in 0°-position. (Rudder horn leading
edge in alignment with the leading edge of the vertical sta-
bilizer.)
3 Replace the control cables and adjust the length per Chap-
ter 27-20-03 if necessary.
4 Check if the rudder travel is within the given tolerances (left/
right 30°, +0°/-2°).
5 If the rudder travel is out of limits, contact the manufac-
turer for advice.
27-20-01 Bottom Hinge Bracket
Removal/Installation
1 Remove the rudder per Chapter 27-20-00.
2 Loosen the attachment bolts.
3 Remove the bottom hinge bracket with the travel stop plate.
4 Install in reverse sequence of removal.
